Machine Type

A3 Color Laser Multifunctional

Core Function

Print, Copy, Scan, Send, Store and Optional Fax

Processor

Canon Dual Custom Processor (Shared)

Control Panel

25.64cm (10.1in) TFT LCD WSVGA Color Touch panel

Memory

RAM: Main CPU: 2GB
Image Processing CPU: 2GB + 1GB^*1

Storage

Standard: (SSD) 256GB
Optional: (SSD) 1TB

Interface Connection

NETWORK
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n);
Optional: NFC, Bluetooth Low Energy

OTHERS
Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1;
Optional: Serial Interface, Copy Control Interface

Paper Supply Capacity (A4, 80g/m²)

Standard: 1 200 sheets
100-sheet Multi-purpose tray x 1
550-sheet Paper cassette x 2,
Maximum: 6 350 sheets (with High Capacity Cassette Feeding Unit-C1 + Paper Deck Unit-F1)

Paper Output Capacity (A4, 80g/m²)

Standard: 250 sheets
Maximum: 3,450 Sheets (with Staple Finisher-AB1 or Booklet Finisher-AB1 and 3rd Copy Tray Kit-A1)

Finishing Capabilities^*2

Standard: Collate, Group
With Options: Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand

Supported Media Types

Multi-purpose tray:
Thin, Plain, Recycled, Colour, Heavy, Coated, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope

Paper Cassette (Upper/Lower):
Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead, Envelope^*3

Supported Media Sizes

Multi-purpose tray:
Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom size: 98.0 x 139.7 mm to 320.0 x 457.2 mm
Free Size: 98.0 x 139.7 mm to 320.0 x 457.2 mm
Envelopes: COM 10 No.10, Monarch, DL, ISO-C5
Envelope custom size: 98.0 x 90.0 mm to 320.0 x 457.2 mm

Upper Cassette:
Standard size: A4, A5, A5R, A6R, B5
Custom Size: 98.0 x 148.0 mm to 297.0 x 215.9 mm
Envelopes: COM10 No.10, Monarch, DL, ISO-C5

Lower Cassette:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom size: 98.0 x 148.0 mm to 304.8 x 457.2 mm
Envelopes: COM10 No.10, Monarch, DL, ISO-C5

Supported Media Weights

Multi-purpose tray: 52 to 300g/m²
Paper Cassette (Upper/Lower): 52 to 256g/m²
Duplex: 52 to 256 g/m²

Warm-up Time

Quick Startup Mode: 4 Seconds or less^*4

From Sleep Mode:
7s or Less (iR-ADV DX C5870i)
6s or Less (iR-ADV DX C5860i/C5850i/C5840i)

From Power On: 6s or less^*5

Dimensions (W x D x H)

iR-ADV DX C5870i/C5860i/C5850i/C5840i: 620 x 722 x 937 mm

Installation Space (W x D)

iR-ADV DX C5870i/C5860i/C5850i/C5840i:
Basic: 1 138 x 1 162 mm (Right Cover Open with Multi-purpose tray extended + Cassette Drawers Open)
Fully Configured: 1 866 x 1 162 mm (Staple Finisher-AB1/Booklet Finisher-AB1 with the extension tray extended + Paper Deck Unit-F1 + Cassette Drawers open)

Weight^*6

iR-ADV DX C5870i: Approx. 110 kg
iR-ADV DX C5860i/C5850i: Approx. 107 kg
iR-ADV DX C5840i: Approx. 106 kg

Copy Speed (Black & White and Color)

iR-ADV DX C5870i
Up to 70 pages per minute (A4, A5^*7, A5R, A6R^*7), up to 36 pages per minute (A3), up to 42 pages per minute (A4R)

iR-ADV DX C5860i
Up to 60 pages per minute (A4, A5^*7, A5R, A6R^*7), up to 32 pages per minute (A3), up to 36 pages per minute (A4R)

iR-ADV DX C5850i
Up to 50 pages per minute (A4, A5^*7, A5R, A6R^*7), up to 27 pages per minute (A3), up to 30 pages per minute (A4R)

iR-ADV DX C5840i
Up to 40 pages per minute (A4, A5^*7, A5R, A6R^*7), up to 21 pages per minute (A3), up to 24 pages per minute (A4R)

First-Copy-Out Time (A4, Black& White /Color)

iR-ADV DX C5870i:
Approx. 2.7 / 3.7s or less

iR-ADV DX C5860i:
Approx. 2.9 / 4.2s or less

iR-ADV DX C5850i:
Approx. 3.4 / 4.9s or less

iR-ADV DX C5840i:
Approx. 4.1 / 6.1s or less

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9 999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

Variable zoom: 25% to 400% (1% Increments)
Preset reduction/enlargement: 25%, 50%, 61%, 70%, 81%, 86%, 100% (1:1), 115%, 122%, 141%, 200%, 400%

Type

Single-pass Duplexing Automatic Document Feeder^*10 [2-sided to 2-sided (Automatic)]

Document Feeder Paper Capacity (80g/m²)

Up to 200 Sheets

Acceptable Originals and Weights

Platen: Sheet, Book, and 3-Dimensional Objects

Document Feeder media weight:
1-sided scanning: 38 to 220 g/m² (Black & White, Color)
2-sided scanning: 38 to 220 g/m² (Black & White, Color)

An acceptable weight of A6R or smaller is 50 to 220g/m²

Supported Media Sizes

Platen scanning size: up to 297.0 x 431.8 mm

Document Feeder media size:
A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6R
Custom size: 70.0 x 139.7 mm to 304.8 x 431.8 mm

Scan Speed (Black & White/Color, A4)

1-sided Scanning:
135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy),
2-sided Scanning:
270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy)

Scan Resolution (dpi)

Scan for Copy: 600 x 600
Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
Scan for Fax: 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows® 8.1/10/Server2012/Server2012 R2/Server 2016
As of Mar. 2020

Destination

Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV, Mail Box
Optional: Super G3 FAX, IP Fax

Address Book

LDAP (2,000) / Local (1,600) / Speed dial (200)

Send Resolution (dpi)

Push: up to 600 x 600
Pull: up to 600 x 600

Communication Protocol

File: FTP(TCP/IP), SMB3.0 (TCP/IP), WebDAV
E-mail/I-Fax: SMTP, POP3

File Format

TIFF, JPEG, PDF (Limited Colour, Compact, Searchable, Apply policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

Maximum Number of Connection Lines

4

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal)

Sending / Receiving Size

Sending: A3, A4, A4R, A5^*11, A5R^*11, B4, B5^*12, B5R^*11
Receiving: A3, B4, A4, A4R, A5R, B5, B5R

Fax Memory

Up to 30 000 pages (2 000 jobs)

Speed Dials

Max. 200

Group Dials / Destinations

Max. 199 dials

Sequential Broadcast

Max. 256 addresses

Memory Backup

Yes

Mail Box (Number supported)

100 User Inboxes
1 Memory RX Inbox
50 Confidential Fax Inboxes
Maximum 30 000 Pages (2 000 jobs) Stored

Advanced Box

Communication Protocol: SMB or WebDAV
Supported Client PC: Windows® 8.1/10
Concurrent Connections (Max.): SMB:64, WebDAV:3

Advanced Box Available Disc Space

Standard: 16 GB
(With option: max. 480GB)

Authentication and Access Control

User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login)
Department ID Authentication (Department ID and PIN Login, Function Level Login)
uniFLOW Online Express (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login)
Access Management System (Access Control)

Document Security

Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print^*13)
Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically)
Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration)
BOX Security (Mail Box Password Protected, Advanced Box Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support)
Document Tracking (Secure Watermark)

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception

Device Security

Protecting SSD Data [SSD Data Encryption (FIPS140-2 Validated), SSD Lock], Standard SSD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runtime Intrusion Detection), HCD-PP

Device Management and Auditing

Administrator Password, Digital Certificate and Key Management, Audit Log,
Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Operating Environment

Temperature: 10 to 30ºC
Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

220-240V, 50/60Hz, 6A

Power Consumption

Maximum:
Approx. 2 000 W (iR-ADV DX C5870i)
Approx. 1 800 W (iR-ADV DX C5860i/C5850i/C5840i)

Copying (with DADF continuous scan): Approx. 943 W^*14
Standby: Approx. 53.4 W^*14
Sleep mode: Approx. 0.8 W^*15

Toner Cartridge/s

NPG-83 Toner BK/C/M/Y
NPG-83L Toner C/M/Y

Tracking and Reporting

Universal Login Manager (ULM)
uniFLOW Online Express

Remote Management Tools

iW Management Console
eMaintenance
Content Delivery System

Scanning Software

Network ScanGear

Optimisation Tools

Canon Driver Configuration Tool

Platform

MEAP (Multifunctional Embedded Application Platform)

Document Publishing

iW DESKTOP

Cassette Feeding Unit-AQ1

Paper Capacity: 2 x 550 sheets (80 g/m²)
Paper Type: Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead
Paper Size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom size: 98.0 x 148.0 mm to 304.8 x 457.2 mm
Paper Weight: 52 to 256 g/m²
Dimensions (W x D x H): 620 x 660 x 251 mm (attached to the main unit)
Weight: Approx. 22 kg

High Capacity Cassette Feeding Unit-C1

Paper Capacity: 2,450 sheets (80 g/m²)
Paper Type: Thin, Plain, Recycled, Colour, Heavy, Bond, Pre-punched, Letterhead
Paper Size: A4
Paper Weight: 52 to 256 g/m²
Dimensions (W x D x H): 620 x 660 x 251 mm (attached to the main unit)
Weight: Approx. 29 kg

Paper Deck Unit-F1

Paper Capacity: 2 700 sheets (80 g/m²)
Paper Type: Thin, Plain, Colour, Recycled, Heavy, Pre-punched
Paper Size: A4, B5
Paper Weight: 52 to 256 g/m²
Dimensions (W x D x H): 344 x 630 x 440 mm (attached to the main unit)
Weight: Approx. 31 kg

Card Readers

Copy Card Reader Attachment-B7
IC Card Reader Box for Numeric Keypad-A1
Copy Card Reader-F1

Others

Tab Feeding Attachment-F1
Buffer Pass Unit-P1
Utility Tray-B1
Numeric Keypad-A2

Data Security

250GB SSD-A1
1TB SSD-A1
Memory Mirroring Kit-A1

Print Accessories

PCL International Font Set-A1
PCL Asian Font Set-A1
PS Printer Kit-BE1

Barcode Printing

Barcode Printing Kit-D1

EFI-Fiery Based Controller

imagePASS-R1

EFI-Fiery Based Controller Options

Fiery Compose
Fiery Impose
Fiery Impose and Compose
Hot Folders License

System Accessories

NFC Kit-E2
Serial Interface Kit-K3
Copy Control Interface Kit-A1
Connection Kit-A3 for Bluetooth LE

Fax Accessories

Super G3 FAX Board-AX1
Super G3 2nd Line Fax Board-AX1
Super G3 3rd/4th Line Fax Board-AX1
Remote Fax Kit-A1
IP FAX Expansion Kit-B1

Accessibility Accessories

ADF Access Handle-A1
Voice Guidance Kit-G1
Voice Operation Kit-D1

Consumables

Staple Cartridge-Y1
Staple-P1
