Machine Type

A3 Monochrome Laser Multifunctional

Core Functions

Print, Copy, Scan, Send, Store and Optional Fax

Processor

Canon Dual Custom Processor (Shared)

Control Panel

Standard: 25.654cm (10.1in) TFT LCD WSVGA Color Touch panel

Memory

Standard: 3.0GB RAM

Hard Disk Drive

Standard^*1: 320Gb (available disk space: 250 Gb)
Optional: 250Gb, 1TB

Mirroring Hard Disk Drive

Optional

Interface Connection

NETWORK
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)
Optional: NFC, Bluetooth Low Energy

OTHERS
Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1
Optional: Serial Interface, Copy Control Interface

Paper Supply Capacity (A4, 80g/m²)

Standard:
1 200 sheets
100-sheet Multi-purpose tray x 1
550-sheet cassette x 2

Maximum:
6 350 sheets (with High Capacity Cassette Feeding Unit-B1and Paper Deck Unit-F1)

Paper Output Capacity (A4, 80g/m²)

Standard: 250 Sheets
Maximum: 3 350 Sheets (with Buffer Pass-N1 + Staple Finisher-Y1 or Booklet Finisher-Y1)

Finishing Capabilities

Standard: Collate, Group
With options: Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand

Supported Media Types

Multi-purpose tray:
Thin, Plain, Heavy, Colour, Recycled, Pre-punched, Transparency, Tracing, Label, Bond, Envelope

Upper/Lower Cassette:
Thin, Plain, Heavy, Colour, Recycled, Pre-punched

Supported Media Sizes

Multi-purpose tray:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom Size: 98.0 x 148.0 mm to 297.0 x 431.8 mm
Free Size: 98.0 x 148.0 mm to 297.0 x 431.8 mm
Envelope: COM10 No.10, Monarch, DL, ISO-C5
Envelope custom size: 98.0 x 148.0mm to 297.0 x 431.8mm

Upper Cassette:
Standard size: A4, A4R, A5R, B4, B5, B5R
Custom size: 139.7 x 182.0 mm to 297.0 x 390.0 mm

Lower Cassette:
Standard size: A3, A4, A4R, A5R, B4, B5, B5R
Custom size: 139.7 x 182.0 mm to 297.0 x 431.8 mm
Envelope^*2: COM10 No.10, Monarch, DL, ISO-C5

Supported Media Weights

Multi-purpose tray: 52 to 220g/m²^*3
Upper/Lower Cassette: 60 to 220g/m²
Duplex: 60 to 105g/m²

Warm-up Time

Quick Startup Mode: 4s or less^*4
From Sleep Mode: 10s or less
From Power On: 24s or less^*5

Dimensions (W x D x H)

With Platen Cover-Y2: 608 x 713 x 822 mm
With Single Pass DADF-C1: 608 x 722 x 932 mm
With DADF-BA1: 608 x 719 x 926 mm

Installation Space (W x D)

Basic:
1 116 x 1 160 mm (with Platen Cover Type Y2 + Multi-purpose tray open/extension tray extended + Paper Cassette open)
1 116 x 1 169 mm (with Single Pass DADF-C1 + Multi-purpose tray open/extension tray extended + Paper Cassette open)
1 116 x 1, 66 mm (with DADF-BA1 + Multi-purpose tray open/extension tray extended + Paper Cassette open)

Fully Configured:
1 811 x 1 169 mm (with Single Pass DADF-C1 + Paper Deck Unit-F1 + Booklet Finisher-Y1 with extension tray extended and Saddle unit drawn)
1 811 x 1 166 mm (with DADF-BA1 + Paper Deck Unit F1 + Booklet Finisher-Y1 with extension tray extended and Saddle unit drawn)

Weight

iR-ADV DX 4751/4745/4735:
With Platen Cover-Y2: Approx. 76.1 kg including toner
With Single Pass DADF-C1: Approx. 89.0 kg including toner
With DADF-BA1: Approx. 82.5 kg including toner

iR-ADV DX 4725i:
With Platen Cover-Y2: Approx. 75.0 kg including toner
With Single Pass DADF-C1: Approx. 87.9 kg including toner
With DADF-BA1: Approx. 81.4 kg including toner

Print Speed

iR-ADV DX 4751:
Up to 51 pages per minute (A4), Up to 37 pages per minute (A4R), Up to 25 pages per minute (A3), Up to 20 pages per minute (A5R)

iR-ADV DX 4745:
Up to 45 pages per minute (A4), Up to 32 pages per minute (A4R), Up to 22 pages per minute (A3),Up to 20 pages per minute (A5R)

iR-ADV DX 4735:
Up to 35 pages per minute (A4), Up to 32 pages per minute (A4R), Up to 22 pages per minute (A3), Up to 20 pages per minute (A5R)

iR-ADV DX 4725:
Up to 25 pages per minute (A4), Up to 17 pages per minute (A4R), Up to 15 pages per minute (A3), Up to 17 pages per minute (A5R)

Print Resolution (dpi)

1 200 x 1 200

Page Description Languages

Standard: UFR II, PCL6 (optional)
Optional: Adobe®PostScript®3™

Direct Print

Supported file types: PDF, EPS, TIFF/JPEG, and XPS

Printing from Mobile and Cloud

AirPrint, Mopria, Google Cloud Print, Canon Business Print and uniFLOW Online

A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements. Please contact your sales representative for further information

Fonts

PS fonts: 136 Roman
PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T^*6 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts^*7

Print Features

Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/ Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer

Operating System

UFRII: Windows® 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019, Mac OS X (10.10 or later)

PCL (optional): Windows® 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019
PS: Windows® 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019, Mac OS X (10.10 or later)

PPD: Windows® 7 / 8.1 / 10, Mac OS X (10.9 or later)

As of July, 2019.

Copy Speed

iR-ADV DX 4751:
Up to 51 pages per minute (A4), Up to 37 pages per minute (A4R), Up to 25 pages per minute (A3), Up to 20 pages per minute(A5R)

iR-ADV DX 4745:
Up to 45 pages per minute (A4), Up to 32 pages per minute (A4R), Up to 22 pages per minute (A3),Up to 20 pages per minute (A5R)

iR-ADV DX 4735:
Up to 35 pages per minute (A4), Up to 32 pages per minute (A4R), Up to 22 pages per minute (A3), Up to 20 pages per minute (A5R)

iR-ADV DX 4725:
Up to 25 pages per minute (A4), Up to 17 pages per minute (A4R), Up to 15 pages per minute (A3), Up to 17 pages per minute (A5R)

First-Copy-Out Time (A4)

iR-ADV DX 4751: Approx. 3.7s or less
iR-ADV DX 4745: Approx. 3.8s or less
iR-ADV DX 4735: Approx. 3.8s or less
iR-ADV DX 4725: Approx. 5.2s or less

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9 999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

Variable zoom: 25% to 400% (1% Increments)

Preset reduction/enlargement: 25%, 50%, 61%, 70%, 81%, 86%, 100% (1:1), 115%, 122%, 141%, 200%, 400%

Copy Features

Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Job Build, N on 1, Add Cover, Insert Sheets, Different Size Originals, Page Numbering, Copy Set Numbering, Sharpness, Erase Frame, Secure Watermark, Print Date, Gutter, Print & Check, Negative/Positive, Repeat Images, Merge Job Blocks, Mirror Image, Store in Mail Box, Superimpose Image, Copy ID Card, Skip Blank Pages, Free Size Original, Reserved copy, Copy Sample

Type

Standard: Colour Flatbed Scan Unit
Optional: Platen Cover, Single Pass DADF-C1^*8 or DADF-BA1 [2-sided to 2-sided (Automatic with DADF)]

Document Feeder Paper Capacity (80g/m²)

Single Pass DADF-C1: up to 200 sheets
DADF-BA1: up to 100 sheets

Acceptable Originals and Weights

Platen: Sheet, Book and 3-Dimensional objects

Document Feeder media weight:
Single Pass DADF-C1^*9:
1-sided scanning: 38 to 220g/m²
2-sided scanning: 38 to 220g/m²
DADF-BA1:
1-sided scanning: 38 to 128g/m² (Black & White),
64 to 128g/m² (Colour)
2-sided scanning: 50 to 128g/m² (Black & White),
64 to 128g/m² (Colour)

Supported Media Sizes

Platen max. scanning size: up to 297.0 x 431.8 mm

Document Feeder media size:
Single Pass DADF-C1:
A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6R, Custom size: 70.0 x 139.7 mm to 304.8 x 431.8 mm

DADF-BA1:
A3, A4, A4R, A5, A5R, B4, B5, B5R, B6, Custom size: 139.7 x 128 mm to 297.0 x 431.8 mm

Scan Speed (images per minute, Black & White /Colour, A4)

Single Pass DADF-C1:
1-sided Scanning: 135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy)
2-sided Scanning: 270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy)

DADF-BA1:
1-sided Scanning: 70/70 (300 x 300 dpi, send), 51/51 (600 x 600 dpi, copy)
2-sided Scanning: 35/35 (300 x 300 dpi, send), 25.5/25.5 (600 x 600 dpi, copy)

Scan Resolution (dpi)

Scan for Copy: 600 x 600
Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
Scan for Fax: 600 x 600

Pull Scan Specifications

Color Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows® 7 / 8.1/ 10 / Server 2008 /Server 2008 R2/ Server 2012/ Server 2012 R2 / Server 2016

Scan Method

Push Scan, Pull Scan, Scan to Box, Scan to Advanced Box, Scan to Network, Scan to USB Memory Key, Scan to Mobile device, Scan to cloud (uniFLOW Online)

Destination

Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV, Mail Box
Optional: Super G3 FAX, IP Fax

Address Book

LDAP (2,000)/Local (1,600)/Speed dial (200)

Send Resolution (dpi)

Push: up to 600 x 600
Pull: up to 600 x 600

Communication Protocol

File: FTP (TCP/IP), SMB3.0 (TCP/IP), WebDAV
E-mail/I-Fax: SMTP, POP3

File Format

Standard: TIFF, JPEG, PDF (Compact, Searchable, Apply policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

Universal Send Features

Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Copy Ratio, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Pages

Maximum Number of Connection Lines

4

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400x400 (Ultra Fine), 200x400 (Super Fine), 200x200 (Fine), 200x100 (Normal)

Sending/Receiving Size

Sending: A3, A4, A4R, A5^*10, A5R^*10, B4, B5^*11, B5R^*10
Receiving: A3, A4, A4R, A5R , B4, B5, B5R

FAX Memory

Up to 30 000 pages (2 000 jobs)

Speed Dials

Maximum 200

Group Dials / Destinations

Maximum 199 dials

Sequential Broadcast

Maximum 256 addresses

Memory Backup

Yes

Fax Features

Sender's Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log

Mail Box (Number supported)

100 User Inboxes
1 Memory RX Inbox
50 Confidential Fax Inboxes
Maximum 30 000 Pages (2 000 jobs) Stored

Advanced Box

Communication Protocol: SMB or WebDAV
Supported Client PC: Windows® 8.1/10
Concurrent Connections (Maximum): SMB:64, WebDAV:3

Advanced Box Available Disc Space

Standard:16 GB
(With option: maximum 480GB)

Advanced Box Features

Authentication for Advanced Box Log-in, Sort Function, Printing a PDF File with a Password, imageWARE Secure Audit Manager Support, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore

Authentication and Access Control

Standard: User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online Express (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)

Document Security

Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print^*12), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Box Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Scan Lock (QR code), Document Tracking (Secure Watermark)

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception

Device Security

Protecting HDD Data (HDD Data Encryption (FIPS140-2 Validated), HDD Data Overwrite Erase, HDD Lock), Standard HDD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runtime Intrusion Detection)
Optional: IEEE2600.2 (Common Criteria Certification) (available at a later date)

Device Management and Auditing

Administrator Password, Digital Certificate And Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Operating Environment

Temperature: 10 to 30 ºC
Humidity: 20 to 80 % RH (Relative Humidity)

Power Requirements

220-240V, 50-60Hz, 5.6A

Power Consumption

Maximum: Approx. 1 500 W
Standby: Approx. 38 W^*13
Sleep mode: Approx. 0.9 W^*14

Toner Cartridges

NPG-73 Toner BK

Toner (Estimated Yield @ 6% Coverage)

NPG-73 Toner BK: 42 100 pages

Tracking and Reporting

Universal Login Manager (ULM)
uniFLOW Online Express

Remote Management Tools

iW Management Console
eMaintenance
Content Delivery System

Scanning Software

Network ScanGear

Optimisation Tools

Canon Driver Configuration Tool
NetSpot Device Installer

Platform

MEAP (Multifunctional Embedded Application Platform)

Document Publishing

IW DESKTOP

Cassette Feeding Unit-AN1

Paper Capacity: 550 sheets x 2 (80g/m²)
Paper Type: Thin, Plain, Heavy, Color, Recycled, Pre-punched
Paper Size: A3, A4, A4R, A5R, B4, B5, B5R
Custom size: 139.7 x 182.0 mm to 297.0 to 390.0 mm
Paper Weight: 60 to 220g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 565 x 650 x 248 mm (attached to the main unit)
Weight: Approx. 23.5 kg

High Capacity Cassette Feeding Unit-B1

Paper Capacity: 2,450 sheets (80g/m²)
Paper Type: Thin, Plain, Heavy, Color, Recycled, Pre-punched
Paper Size: A4 Paper Weight: 60 to 220g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 565 x 650 x 248 mm (attached to the main unit)
Weight: Approx. 28.0 kg

Paper Deck Unit-F1

Paper Capacity: 2 700 sheets (80g/m²)
Paper Type: Thin, Plain, Heavy Color, Recycled, Pre-punched
Paper Size: A4, B5
Paper Weight: 60 to 128g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 344 x 630 x 440 mm (attached to the main unit)
Weight: Approx. 31.0 kg

Card Readers

Copy Card Reader-F1
Copy Card Reader Attachment-B7

Others

Platen Cover Type-Y2
Envelope Feeder Attachment Kit-D1
Utility Tray-B1
Numeric Keypad-A1

Device Security

iR-ADV Security Kit-AN1 for IEEE 2600 Common Criteria Certification (available at a later date)

Data Security

HDD Mirroring Kit-J1
6.35cm /250GB HDD-N1
6.35cm /1TB HDD-P1

Print Accessories

PCL (optional) International Font Set-A1
PCL (optional) Asian Font Set-A1
PS Printer Kit-BG1/CC1

Barcode Printing

Barcode Printing Kit-D1

System Accessories

Copy Control Interface Kit-A1
Serial Interface Kit-K3
Connection Kit-A2 for Bluetooth LE
NFC Kit-E1

FAX Accessories

Super G3 Fax Board-BF1
Super G3 2nd Line Fax Board-BF1
Super G3 3rd/4th Line Fax Board-AS1
Remote Fax Kit-A1
IP Expansion Kit-B1

Accessibility Accessories

ADF Access Handle-A1
Voice Guidance Kit-G1
Voice Operation Kit-D1

Staple Cartridge

Staple-P1
Staple Cartridge-Y1
