Machine Type

A3 Colour Laser Multifunctional

Core Function

Print, Copy, Scan, Send, Store and Optional Fax

Control Panel

17.78cm (7in) TFT LCD WVGA colour Touch panel

Memory

Standard: 2.0 GB RAM

Storage

eMMC: 30GB^*1

Interface Connection

NETWORK
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)

OTHERS
Standard: USB 2.0 (Host) x2, USB 2.0 (Device) x1

Paper Supply Capacity (A4, 80g/m²)

Standard: 1,200 sheets
Maximum: 2300 sheets (with Cassette Feeding Unit-AW1)

Paper Output Capacity (A4, 80g/m²)

Standard: 250 sheets
Maximum: 650 sheets (with Inner Finisher-L1 and Copy Tray-T1)

Finishing Capabilities^*2

Collate, Group, Offset, Staple, Hole Punch, Eco Staple, Staple On Demand

Supported Media Types

Multi-purpose Tray:
Thin, Plain, Heavy^*3, Recycled, Coated, Colour, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Envelope

Upper Cassette:
Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead, Envelope^*4

Lower Cassette:
Thin, Plain, Heavy, Recycled, Colour, Bond, Transparency, Pre-punched, Letterhead, Envelope^*5

Supported Media Sizes

Multi-purpose tray:
Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom size: 98.4 x 139.7 mm to 320.0 x 457.2 mm
Envelopes: COM10 No.10, Monarch, ISO-C5, DL
Envelope custom size: 98.0 x 98.0 mm to 320.0 x 457.2 mm

Upper Cassette:
Standard size: A4, A5, A5R, A6R, B5
Custom Size: 105.0 x 148.0 mm to 297.0 x 215.9 mm
Envelope^*4: ISO-C5

Lower Cassette:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom Size: 105.0 x 148.0 mm to 304.8 x 457.2 mm
Envelopes^*5: COM10 No.10, Monarch, DL

Supported Media Weights

Multi-purpose tray: 52 to 300 g/m²
Upper/Lower Cassette: 52 to 256 g/m²
Duplex: 52 to 220 g/m²

Warm-up Time
(Quick start mode: ON)

4s or Less^*6
From Sleep Mode: 10s or less

10s or Less^*7

Dimensions (W x D x H)

565 x 687 x 891 mm

Installation Space (W x D)

1168 x 1116 mm

Weight

Approx. 76.9 kg including toner (with DADF-BA1)

Print Speed (Black & White /Color)

1-sided:
Up to 26/26 pages/minute (A4, A5, A5R, A6R),
Up to 20/20 pages/minute (A4R),
Up to 15/15 pages/minute (A3)

2-sided: Up to 13/13 pages/minute (A4, A5R),
Up to 10/10 pages/minute (A4R),
Up to 7/7 pages/minute (A3)

Print Resolution (dpi)

600 × 600
1200 x 1200 (half-speed)

Page Description Languages

Standard: UFR II, PCL6 (optional)
Optional: Adobe® PostScript® 3™

Direct Print

Supported file types:
RUI: PDF, EPS, TIFF/JPEG, XPS
USB Memory: PDF, TIFF/JPEG, XPS
Network Place: PDF, TIFF/JPEG, XPS

Printing from Mobile and Cloud Application

AirPrint, Mopria, Canon PRINT Business, uniFLOW Online and Universal Print

Fonts

PS fonts: 136 Roman
PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T^*8 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts^*9

Print Features

Secure Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/ Orientations, Toner Reduction, Poster Printing, Forced hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer

Operating System

UFRII: Windows® 8.1 / 10 / Server 2012 / Server 2012 R2 / Server 2016 / Server 2019, MAC OS X (10.11 or later)

PCL: Windows® 8.1 / 10 / Server 2012 / Server 2012 R2 / Server 2016 / Server 2019

PS: Windows® 8.1 / 10 / Server 2012 / Server 2012 R2 / Server 2016 / Server 2019, MAC OS X (10.11 or later)

PPD: Windows® 8.1/10, MAC OS X (10.11 or later)

Copy Speed (BW/CL)

1-sided:
Up to 26/26 pages per minute (A4, A5, A5R, A6R),
Up to 20/20 pages per minute (A4R),
Up to 15/15 pages per minute (A3)

2-sided:
Up to 13/13 pages per minute (A4, A5R),
Up to 10/10 pages per minute (A4R),
Up to 7/7 pages per minute (A3)

First-Copy-Out Time (A4, Black and White)

Approx. 7.0s / 8.7s or less

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9,999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

25% - 400% (1% Increments)
Preset reduction/enlargement: 25%, 50%, 61%, 70%, 81%, 86%, 100%, 115%, 122%, 141%, 200%, 400%

Type

Optional: DADF-BA1 [2-sided to 2-sided] or Platen Cover-Y3
DADF: Duplexing Automatic Document Feeder

Document Feeder Paper Capacity (80 g/m²)

Up to 100 sheets

Acceptable Originals and Weights

Platen: Sheet, Book and 3-Dimensional objects

Document Feeder media weight:
1-sided scanning: 30 to 128 g/m² (Black & White), 64 to 128 g/m² (Colour)
2-sided scanning: 50 to 128 g/m² (Black & White), 64 to 128 g/m² (Colour)

Supported Media Sizes

Platen: max. scanning size: 297.0 x 431.8 mm

Document Feeder media size:
A3, A4, A4R, A5, A5R, B4, B5, B5R, B6

Custom size: 128.0 x 139.7 mm to 297.0 x 431.8 mm

Scan Speed (images per minute: Black & White/Colour, A4)

DADF:
1-sided Scanning: 70/70 (300 dpi, send), 51/42 (600 dpi, copy)
2-sided Scanning: 35/35 (300 dpi, send), 25.5/25.5 (600 dpi, copy)

Scan Resolution (dpi)

Scan for Copy: up to 600 x 600

Scan for Send:
(Push, Black & White) up to 600 x 600, (Pull, BW) up to 600 x 600
(Push,CL) up to 300 x 300, (Pull, CL) up to 300 x 300

Scan for Fax: up to 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA.

Supported OS: Windows® 8.1 / 10 / Server2012 / Server2012 R2 / Server 2016 / Server 2019

Scan Method

PushScan, PullScan, Scan to Network, Scan to USB Memory Key, Scan to Mobile device, Scan to cloud-based services (uniFLOW Online/Online Express)

Destination

Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV
Optional: Super G3 FAX

Address Book

LDAP (2,000) / Local (1,600) / One-touch (200)

Send Resolution (dpi)

Push: 100 x 100, 150 x 150, 200 x 100 (Normal), 200 x 200 (Fine), 200 x 400^*10 (SuperFine), 300 x 300, 400 x400^*10 (UltraFine), 600 x 600^*10

Pull: 75 x 75, 100 x 100, 150 x 150, 200 x 200, 300 x 300, 400 ｘ 400^*10, 600 x 600^*10

Communication Protocol

File: FTP (TCP/IP), SMB3.0 (TCP/IP), WebDAV
Email/iFax: SMTP (send), POP3 (receive)

File Format

Standard: TIFF (MMR), JPEG^*11, PDF (Compact, Searchable, PDF/A-1b, Encrypted), XPS (Compact, Searchable), PDF/XPS (Device Signature), Office Open XML (PowerPoint, Word)

Optional: PDF (Trace & Smooth), PDF/XPS (User Signature)

Maximum Number of Connection Lines

1

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal)

Sending / Receiving Size

Sending: A3, A4, A4R, A5^*12, A5R^*12, B4, B5^*13, B5R^*12
Receiving: A3, A4, A4R, A5R, B4, B5, B5R

Fax Memory

Up to 30 000 pages

Speed Dials

Max. 200

Group Dials / Destinations

Max. 199 dials

Sequential Broadcast

Max. 256 addresses

Memory Backup

Yes

Memory Media

Standard: USB Memory

Authentication and Access Control

User Authentication(Picture Login, Picture and PIN Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online Express (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)

Document Security

Print Security (Secure Print, Encrypted SecurePrint, Forced Hold Printing, uniFLOW Secure Print^*14), Recieve Data Security(Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS^*15), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support)

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMPv3, Firewall, Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Scan and Send -Virus Concerns for E-mail Reception

Device Security

Standard Storage Initialize, Job Log Conceal Function, Protecting MFP Software Integrity, Verify System at Startup, Runtime Intrusion Detection

Device Management and Auditing

Administrator Password, Digital Certificate and Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Security Policy Setting

Operating Environment

Temperature: 10 to 30 ºC
Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

220-240 V 50/60 Hz 4 A

Power Consumption

Maximum: Approx. 1,500 W
Standby: Approx. 44.0 W^*16
Sleep mode: Approx. 2.0 W^*17, Approx. 1.0 W^*18

Toner

NPG-67 TONER BK
NPG-67 TONER C/M/Y

Tracking and Reporting

uniFLOW Online Express

Remote Management Tools

iW Management Console
eMaintenance
Content Delivery System

Scanning Software

ScanGear

Optimisation Tools

Canon Driver Configuration Tool

Document Publishing

iW DESKTOP

Cassette Feeding Unit-AW1

Paper Capacity: 550 sheets x 2 (1,100 sheets) (80 g/m²)
Paper Type: Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead
Paper Size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R,
Custom Size: 105.0 x 148.0 mm to 304.8 x 457.2 mm
Paper Weight: 52 to 256 g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 565 x 635 x 248 mm
Weight: Approx. 16.0 kg

Inner 2way Tray-M1

Tray Capacity (with 80 g/m² paper)
Upper tray:
SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R: 100 sheets
Lower tray (standard tray):
A4, A5, A5R, A6R, B5, B5R: up to 250 sheets
SRA3, A3, A4R, B4: up to 100 sheets

Paper Weight: 52 to 300 g/m²
Dimensions (W x D x H): 428 x 405 x 88 mm
Weight: Approx. 0.7 kg

Copy Tray-T1

Capacity (with 80 g/m² paper):
A4, A5R, B5, B5R: 100 sheets
A3, A4R, B4: 75 sheets

Dimensions (W x D x H): 442 × 373 × 176 mm (attached to the main unit, when the extension tray is extended)
Weight: Approx. 0.5 kg

Inner Finisher-L1

Tray Capacity (with 80 g/m² paper):
Upper Tray:
SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R: approx. 45 sheets
Lower Tray:
A4, A5, A5R, B5: approx. 500 sheets
SRA3, A3, A4R, B4, B5R: 250 sheets
A6R: 30 sheets
Envelope: 10 sheets

Paper Weight: 52 to 300 g/m²
Staple Position:
Corner, Double
Staple Capacity:
A4, B5: 50 sheets (52 to 90 g/m²)
A4R: 40 sheets (52 to 90 g/m²)
A3, B4: 30 sheets (52 to 90 g/m²)

Eco Staple:
A3, A4, B4, B5:
10 sheets (52 to 64 g/m²)
8 sheets (65 to 81.4 g/m²)
6 sheets (82 to 105 g/m²)

Staple On Demand: approx. 40 sheets (80 g/m²)
Dimensions (W x D x H): 727× 525 × 225 mm (attached to the main unit, when the extension tray is extended)
Weight: Approx. 9.1 kg

Inner 2/3 Hole Puncher-D1

(Requires Inner Finisher-L1)
Two or Three Holes
Acceptable Punch Paper Weight: 52 to 300 g/m²
Acceptable Punch Paper Size:
Two holes A3, A4, A4R, A5, B4, B5, B5R,
Three holes A3, A4, B4, B5

Inner 2/4 Hole Puncher-D1

(Requires Inner Finisher-L1)
Two or Four Holes
Acceptable Punch Paper Weight: 52 to 300 g/m²
Acceptable Punch Paper Size:
Two holes A3, A4, A4R, A5, B4, B5, B5R,
Four holes A3, A4

Card Readers

Copy Card Reader Attachment-H3
IC Card Reader Attachment-B3
IC Card Reader Attachment-B4
Copy Card Reader-F1

Others

Option Attachment kit for Reader-A2
DADF-BA1
Platen Cover-Y3
Utility Tray-B1

Print Accessories

PCL International Font Set-A1
PCL Asian Font Set-A1
PS Printer Kit-CS1

Send Options

Universal Send Trace & Smooth PDF Kit-A1
Universal Send Digital User Signature Kit-C1

Barcode Printing

Barcode Printing Kit-D1

System Accessories

Copy Control Interface Kit-D1

Fax Accessories

Super G3 FAX Board-BJ1
Remote Fax Kit-A1

Accessibility Accessories

ADF Access Handle-A1
Media Adjustment kit-A1

Staple Cartridges

Staple-P1
