Machine Type

A3 Monochrome Laser Multifunctional

Core Functions

Print, Copy, Scan, Send and Optional Fax

Control Panel

Standard: 17.78cm TFT LCD WVGA Colour Touch panel

Memory

Standard: 2.0GB RAM

Paper Supply Capacity (A4, 80g/m²)

Standard: 1 200 sheets
2 300 sheets (with Cassette Feeding Unit-AN1)

Paper Output Capacity (A4, 80g/m²)

Standard: 250 sheets
545 sheets (with Inner Finisher-J1)

Supported Media Sizes

Upper Cassette 1:
Standard size: A4, A4R, A5R, B4, B5, B5R
Custom size: Minimum 139.7 x 182.0 mm up to 297.0 x 390.0 mm

Lower Cassette 2:
Standard size: A3, A4, A4R, A5R, B4, B5, B5R
Custom size: Minimum 139.7 x 182.0 mm up to 297.0 x 431.8 mm

Multi-purpose tray:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, Envelopes [No. 10(COM 10), Monarch, ISO-C5, DL]
Custom Size/Free Size: Minimum 98.0 x 148.0 to 297.0 x 431.8 mm

Supported Media Weights

Paper Cassettes (1/2): 60 to 128g/m²
Multi-purpose tray: 52 to 220g/m²  (Thin: vertical grain paper feed only: 52 to 59g/m²)
Duplex: 60 to105g/m²

Warm-up Time
(Quick start mode:ON)

12s or less^*1
From Sleep Mode: 10s or less
4s or less^*2

Dimensions (W x D x H)

iR 2645/2635: 586 x 709 x 926 mm (with DADF-BA1)^*3
iR 2630/2625: 586 x 713 x 912 mm (with DADF-AZ1)^*3
iR 2625: 586 x 700 x 818 mm (with Platen Cover type Z)^*3

Installation Space (W x D)

iR 2645/2635: 1363 x 1269 mm (with DADF-BA1)^*4
iR 2630/2625: 1363 x 1273 mm (with DADF-AZ1)^*4
iR 2625: 1363 x 1260 mm (with Platen Cover type Z)^*4

Weight

Standard:
iR 2645/2635: 68.3kg without toner
iR 2630/2625: 66.8kg without toner

Print Speed (ppm)

iR 2645:
45 ppm (A4), 22 ppm (A3)
iR 2630:
30 ppm (A4), 15 ppm (A3)
iR 2625
25 ppm (A4), 15 ppm (A3)

Print Resolution (dpi)

1 200 x 1 200

Page Description Languages

Standard: UFR II
Optional: Genuine Adobe PostScript 3, PCL 6

Fonts

PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T^*5 (Japanese, Korean, Simplified and Traditional Chinese) , Barcode fonts^*6
PS fonts: 136 Roman

Operating System

UFRII: Windows® 7/8.1/10/Server 2008 /Server 2008 R2/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.9 or later)
PCL: Windows® 7/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016/Server 2019
PS: Windows® 7/8.1/10/Server 2008/Server 2008 R2/ Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.9 or later)
PPD: Windows® 7/8.1/10, MAC OS X (10.9 or later)

Copy Speed (ppm)

iR 2645:
45 ppm (A4), 22 ppm (A3)
iR 2630:
30 ppm (A4), 15 ppm (A3)
iR 2625i:
25 ppm (A4), 15 ppm (A3)

First-Copy-Out Time (A4)

iR 2645: 3.9s or less
iR 2630/2625: 5.9s or less

Copy resolution (dpi)

Reading: 600 x 600
Printing: Up to 1 200 x 1 200

Multiple Copies

Up to 9 999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

25% - 400% (1% Increments)

Preset Reductions

25%, 50%, 61%, 70%, 81%, 86%

Preset Enlargements

115%, 122%, 141%, 200%, 400%

Selectable Type

iR2645: Optional Document Feeder(DADF-BA1) or Platen Cover Type Y
iR2630/2625: Optional Document Feeder(DADF-AZ1) or Platen Cover Type Z

Document Feeder Paper Capacity (80g/m²)

DADF-BA1: 100 Sheets
DADF-AZ1: 50 Sheets

Acceptable Originals and Weights

Platen (DADF-BA1):
Sheet, Book, 3-Dimensional Objects
Platen (DADF-AZ1)：
Sheet, Book

Document Feeder media weight:

DADF-BA1:

1-sided scanning: 38 to 128g/m² (BW), 64 to 128g/m² (CL)*7

2-sided scanning: 50 to 128g/m²(BW), 64 to 128g/m² (CL)

DADF-AZ1:

1-sided scanning: 38 to 128g/m² (BW/CL)

2-sided scanning: 38 to 128g/m²(BW/CL)＊8

Supported Media Sizes

Platen: scanning size: 297.0 x 431.8 mm
Document Feeder media size:
DADF-BA1: A3, A4, A4R, A5, A5R, B5, B5R, B6, B4R
Custom size: 128.0 x 139.7 mm to 297.0 x 431.8 mm
DADF-AZ1:
A3, A4, A4R, A5, A5R, B5, B5R, B4R
Custom size: 128.0 x 148.0 mm to 297.0 x 431.8 mm

Scan Speed (ipm: BW/CL; A4)

DADF-BA1:
1-sided Scanning: 55/55 (BW/CL; 300 dpi), 45 (BW; 600 dpi)
2-sided Scanning: 27.5/27.5 ((BW/CL; 300 dpi), 22.5 (BW; 600 dpi)

DADF-AZ1:
1-sided Scanning:35/25 (BW/CL; 300 dpi), 25 (BW; 600 dpi)
2-sided Scanning:12/8 (BW/CL; 300 dpi), 8 (BW; 600 dpi)

Scan Resolution (dpi)

Copy: 600 x 600
Send: (Push) up to 600 x 600, (Pull) up to 600 x 600
Fax: up to 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows® 7/8.1/10
Windows® Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016

Scan Method

Send functionality available on all models
Scan to USB Memory Key: Available on all models
Scan to Mobile Devices and cloud-based services: A range of solutions is available to provide scanning to mobile devices or cloud-based services depending on your requirements. Please contact your sales representative for further information.
TWAIN/WIA Pull scanning available on all models

Destination

E-mail/Internet FAX (SMTP), SMB, FTP, WebDAV, Super G3 FAX (Optional)

Address Book

LDAP (2,000)/Local (1,600)/Speed dial (200)

Send Resolution (dpi)

Push: 600 x 600
Pull: 600 x 600, 400 x 400, 300 x 300, 200 x 200, 150 x 150, 75 x 75

Communication Protocol

File: FTP (TCP/IP), SMB (TCP/IP), WebDAV
E-mail/I-Fax: SMTP (send), POP3 (receive)

File Format

Standard: TIFF (MMR), JPEG^*9, PDF (Compact, PDF A/1-b, Encrypted), XPS (Compact), PDF/XPS (Device Signature)
Optional: PDF (Trace & Smooth), PDF/XPS (User Signature, Searchable), Office Open XML (PowerPoint, Word)

Optional / Standard

Optional on all models

Number of Connection Lines

1

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400 x 400 (Ultrafine), 200 x 400 (Superfine), 200 x 200 (Fine/Photo), 200 x 100 (Normal)

Sending / Recording Size

A3, A4, A4R, A5^*10, A5R^*10, B4, B5^*11, B5R^*10

FAX / Memory

Up to 30 000 pages

Speed Dials

200

Group Dials / Destinations

199 dials

Sequential Broadcast

256 addresses

Memory Backup

Yes

Memory Media

Standard: USB Memory

Authentication

Standard: uniFLOW Online Express, User Authentication, Department ID Authentication, Access Management System, Picture Login
Optional: My Print Anywhere secure print (Requires uniFLOW)

Network

Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP, S/MIME

Document

Standard: Secure Print, Encrypted PDF, Encrypted Secure Print, Device signature
Optional: User signature

Operating Environment

Temperature: 10 to 30 ºC (50 to 86 ºF)
Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

220-240 V , 50/60 Hz , 5.2 Amp

Power Consumption

Maximum: 1500W
Standby: 20W
Sleep mode: 0.6 W

Toner Cartridge/s

NPG-84 Toner Black

Toner (Estimated Yield @ 6% Coverage)

Black: 30 000 impressions (A4)

CASSETTE FEEDING UNIT-AN1

Paper Capacity: 550 sheets x 2 (80g/m²)
Paper Type: Thin, Plain, Thick, Colour, Recycled, Pre-punched
Paper Size: A3, A4, A4R, A5R, B4, B5, B5R, Custom size: 139.7 x 182.0 to 297.0 x 431.8 mm
Paper Weight: 60 to 128g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 565 x 650 x 248 mm (attached to the main unit)
Weight: 23.5kg

ENVELOPE FEEDER ATTACHMENT-D1

Attaches to the 2nd paper drawer for easy envelope feeding. Holds up to 50 envelopes.

INNER 2WAY TRAY-L1

Allows the separation of copies, prints and faxes. Adds a second internal output tray to give a combined output capacity of 350 sheets (upper tray 100 sheets/lower tray 250 sheets).

INNER FINISHER-J1 (Internal)

Number of Trays: 2
Upper Tray Capacity^*12: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R: 45 sheets
Lower Tray Capacity^*12: A4, A5, A5R, B5: 500 sheets, A3, A4R, B4, B5R 250 sheets, A6R: 30 sheets
Paper Weight: 52 to 220g/m²
Staple Position: Corner, Double

Staple Capacity: Corner and Double Stapling:
A4/B5: 50 sheets (52 to 90g/m²)
A3/A4R/B4: 30 sheets (52 to 90g/m²)

Eco Staple:
A3/A4/B4/B5:
5 sheets (52 to 64g/m²)
4 sheets (65 to 81.4g/m²)
3 sheets (81.5 to 105g/m²)

Staple On Demand:
40 sheets (80g/m²)
Dimensions (W x D x H): 604 x 535 x 205 mm (when the extension tray is extended)
Weight: 7.3kg

Card Readers

COPY CARD READER-F1 - Magnetic physical card access system. (Integrates with Department ID, not for use with uniFLOW)
IC Card Reader Box-C2
COPY CARD READER ATTACHMENT-H3 - Attachment kit for Copy Card Reader-F1 only.

Others

UTILITY TRAY-B1 - Additional tray to hold an external USB keyboard
Document Tray-J1
Platen Cover Type Z
Platen Cover Type Y
DADF-AZ1
DADF-BA1

Print Accessories

PCL INTERNATIONAL FONT SET-A1 - Adds PCL support for Andalé Mono WT J/K/S/T (Japanese/Korean/Simplified Chinese/Traditional Chinese).
PS PRINTER KIT-BT1- Provides networked printing support for Adobe PostScript 3 printing.

Send Options

Universal Send Digital User Signature Kit-C1
Universal Send Advanced Feature Set-H1

Barcode Printing

BARCODE PRINTING KIT-D1 - Provides the ability to print 1D and 2D barcodes on output using jet caps technology.

System Accessories

COPY CONTROL INTERFACE KIT-D1: Allows connection (CCVI I/F) between 3rd party copy control terminal and Canon’s iR-ADV range for cost recovery use.

FAX Accessories

SUPER G3 FAX BOARD-AV2
REMOTE FAX KIT-A1 - Enables the device to send and receive fax from another device connected with a fax board

Accessibility Accessories

ADF ACCESS HANDLE-A1 - Attaches to the document feeder, making access easier for seated users.

Staple Cartridge

STAPLE-P1 - For stapling (2 x 5 000 N )
