Machine Type

A4 Monochrome Laser Multifunctional

Core Function

Print, Copy, Scan, Send and Optional Fax

Processor

Canon Dual Custom Processor (Shared)

Control Panel

25.6cm (10.1in) TFT LCD WSVGA Color Touch panel

Memory

Standard: 3.0GB RAM

Hard Disk Drive

Standard^*1: 320GB (available disk space: 250GB)

Interface Connection

NETWORK
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)
Optional: NFC, Bluetooth Low Energy

OTHERS
Standard: USB 2.0 x1 (Host) x 2, USB 3.0 (Host) x1, USB 2.0 (Device) x1
Optional: Copy Control Interface

Paper Supply Capacity (A4, 80 g/m²)

Standard: 650 Sheets

100-sheets Multi-purpose tray x1
550-sheets Paper cassette x1
Maximum: 3 300 Sheets (with High Capacity Cassette Feeding Unit-D1)

Paper Output Capacity (A4, 80 g/m²)

iR-ADV DX 617i: 500 sheets
iR-ADV DX 717iZ: 1 000 sheets

Finishing Capabilities

iR-ADV DX 617i: Collate, Group
iR-ADV DX 717iZ: Collate, Group, Offset^*2, Staple

Supported Media Types

Multi-purpose tray:
Thin, Plain, Recycled, Heavy, Color, Transparency, Bond, Envelope

Paper Cassette:
Thin, Plain, Recycled, Heavy, Color, Labels, Bond, Pre-punched

Supported Media Sizes (Standard)

Multi-purpose tray:
Standard size: A4, A5, A5R, A6, B5
Custom size: 76.2 x 127.0 mm to 216.0 x 355.6 mm
Envelope: COM10 No.10, Monarch, DL, ISO-C5

Paper Cassette:
Standard size: A4, A5, A5R, A6, B5
Custom size: 99.0 x 148.0 mm to 216.0 x 297.0 mm

Supported Media Weights

Multi-purpose tray: 60 to 199g/m²
Cassettes: 60 to 135g/m²
Duplex: 60 to 120g/m²

Warm-up Time

Quick Startup Mode: 4s or less^*3
From Sleep Mode: 10s or less
From Power On: 10s or less^*4

Dimensions (W x D x H)

iR-ADV DX 617i: 500 x 598 x 617 mm
iR-ADV DX 717iZ: 502 x 598 x 814 mm

Installation Space (W x D)

Standard model / Finisher model: 1,052 x 823 mm (with left CRG door open + right door open + the cassette drawer open)

Weight

iR-ADV DX 617i: Approx. 37 kg including toner
iR-ADV DX 717iZ: Approx. 46 kg including toner

Print Speed^*5 (pages per minute)

iR-ADV DX 717iZ
Up to 71 pages per minute (A4), Up to 113 pages per minute (A5), Up to 40 pages per minute (A5R, A6)

iR-ADV DX 617i
Up to 61 pages per minute (A4), Up to 99 pages per minute (A5), Up to 35 pages per minute (A5R, A6)

Print Resolution (dpi)

600 x 600

Page Description Languages

Standard: UFR II, PCL6, Adobe® PostScript® 3™

Direct Print

Supported file types: TIFF, JPEG, PDF, EPS, and XPS

Printing from Mobile and Cloud

AirPrint, Mopria, Google Cloud Print, and Canon Business Print, and uniFLOW Online

Fonts

PS fonts: 136 Roman
PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T^*5 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts^*6

Operating System

UFRII: Windows® 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019, Mac OS X (10.10 or later)

PCL: Windows® 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019

PS: Windows® 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019, Mac OS X (10.10 or later)

PPD: Windows® 7 / 8.1 / 10, Mac OS X (10.9 or later)

Copy Speed^*7 (Black and White and Colour)

iR-ADV DX 717iZ
Up to 71 pages per minute (A4), Up to 113 pages per minute (A5), Up to 40 pages per minute (A5R, A6)

iR-ADV DX 617i
Up to 61 pages per minute (A4), Up to 99 pages per minute (A5), Up to 35 pages per minute (A5R, A6)

First-Copy-Out Time (A4)

Approx. 5s or less

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9 999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

Variable zoom: 25% to 400% (1% Increments)
Preset reduction / enlargement: 25%, 50%, 70%, 81%, 86%, 100% (1:1), 115%, 122%, 141%, 200%, 400%

Standard Type

Single-pass Duplexing Automatic Document Feeder^*8 [2-sided to 2-sided (Automatic)]

Document Feeder Paper Capacity (80g/m²)

Up to 100 Sheets

Acceptable Originals and Weights

Platen: Sheet, Book, and 3-Dimensional Objects

Document Feeder media weight:
1-sided scanning: 42 to 128g/m² (Black and White), 64 to 128g/m² (Colour)
2-sided scanning: 50 to 128g/m² (Black and White), 64 to 128g/m² (Colour)

Note:
Business card: 80 to 220g/m²
Originals with width narrower than A6: 50 to 128g/m²

Supported Media Sizes

Platen scanning size: up to 216.0 x 355.6 mm

Document feeder media size:
A4, A5R, A6, B5
Custom size: 48.0 x 128.0 mm to 216.0 x 355.6 mm
Business card: 48.0 x 85.0 mm to 55.0 x 91.0 mm

Scan Speed (images per minute: Black and White and Colour, A4)

SEND (300 x 300 dpi):
Automatic Color Select "OFF":
1-sided Scanning: 95
2-sided Scanning: 190
Automatic Color Select "ON":
1-sided Scanning: 50
2-sided Scanning: 100

COPY (600 x 600 dpi):
1-sided Scanning: 95
2-sided Scanning: 140

Scan Resolution (dpi)

Scan for Copy: 600 x 600
Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
Scan for Fax: 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows®7/ 8.1/ 10/ Server2008/ Server2008 R2/ Server2012/ Server2012 R2/ Server 2016

Destination

Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV, Mail Box
Optional: Super G3 FAX, IP Fax

Address Book

LDAP (2 000)/Local (1 600)/Speed dial (200)

Send Resolution (dpi)

Push: up to 600 x 600
Pull: up to 600 x 600

Communication Protocol

File: FTP(TCP/IP), SMB3.0 (TCP/IP), WebDAV
E-mail/I-Fax: SMTP, POP3

File Format

Standard: TIFF, JPEG, PDF (Compact, Searchable, Apply policy, Optimize for Web, PDF A/1-b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

Maximum Number of Connection Lines

1

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400x400 (Ultra Fine), 200x400 (Super Fine), 200x200 (Fine), 200x100 (Normal)

Sending / Receiving Size

A4, A5^*9, A6^*9, B5^*9/ A4, A5, B5

Fax Memory

Up to 30 000 pages (2 000 jobs)

Speed Dials

Max. 200

Group Dials / Destinations

Max. 199 dials

Sequential Broadcast

Max. 256 addresses

Memory Backup

Yes

Mail Box (Number supported)

100 User Inboxes,
1 Memory RX Inbox,
50 Confidential Fax Inboxes

Maximum 30,000 pages (2,000 jobs) stored

Advanced Box

Communication Protocol: SMB or WebDAV
Supported Client PC: Windows® 8.1 / 10
Concurrent Connections (Max.): SMB:64, WebDAV:3

Advanced Box Available Disc Space

Standard: 16GB

Authentication and Access Control

User Authentication - Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login)

Department ID Authentication - Department ID and PIN Login, Function Level Login

uniFLOW Online Express - PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login

Access Management System - Access Control

Document Security

Print Security - Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print^*10

Receive Data Security - Confidential Fax Inbox Forwarding Received Documents Automatically

Scan Security - Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration

BOX Security - Mail Box Password Protected, Advanced Box Access Control

Send Data Security - Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support

Document Tracking - Secure Watermark

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception

Device Security

Protecting HDD Data (HDD Data Encryption (FIPS140-2 Validated), HDD Data Overwrite Erase, HDD Lock), Standard HDD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runtime Intrusion Detection)
Optional: Comply IEEE2600.2 (Common Criteria Certification) (available at a later date)

Device Management and Auditing

Administrator Password, Digital Certificate And Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Operating Environment

Temperature: 10 to 30ºC
Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

220-240V, 50/60Hz, 4.8A

Power Consumption

Maximum: 1,500 W
Standby: Approx. 28.92 W^*11
Sleep mode: Approx. 1.0 W^*12

Toner Cartridge/s

T03 Black

Tracking and Reporting

Universal Login Manager (ULM)
uniFLOW Online Express

Remote Management Tools

iW Management Console
eMaintenance
Content Delivery System

Scanning Software

Network ScanGear

Optimisation Tools

Canon Driver Configuration Tool

Platform

MEAP (Multifunctional Embedded Application Platform)

Document Publishing

iW Desktop

Cassette Module-AG1

Paper Capacity: 550 sheets (80g/m²)
Paper Type: Thin, Plain, Recycled, Heavy, Color, Labels, Bond, Pre-punched
Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm
Paper Weight: 60 to 135g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 484 x 450 x 127 mm (attached to the main unit)
Weight: Approx. 7 kg

Envelope Cassette Module-A1

Paper Capacity: 75 sheets (Envelope)
Envelope Size: COM10 No.10, Monarch, DL, ISO-C5
Paper Weight: 80 to 100g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 484 x 450 x 127 mm (attached to the main unit)
Weight: Approx. 7 kg

Cassette Feeding Unit-AR1

Paper Capacity: 550 sheets (80g/m²)
Paper Type: Thin, Plain, Recycled, Heavy, Color, Labels, Bond, Pre-punched
Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm
Paper Weight: 60 to 135g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 642 x 657 x 456 mm (attached to the main unit)
Weight: Approx. 19 kg

High Capacity Cassette Feeding Unit-D1

Upper Cassette:
Paper Capacity: 550 sheets (80g/m²)
Paper Type: Thin, Plain, Recycled, Heavy, Color, Labels, Bond, Pre-punched
Paper Size: A4, A5, A5R, A6, B5
Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm
Paper Weight: 60 to 135g/m²

Lower Cassette:
Paper Capacity: 2,100 sheets (80g/m²)
Paper Type: Thin, Plain, Recycled, Heavy, Color, Bond, Pre-punched
Paper Size: A4
Paper Weight: 60 to 135g/m²
Power Source: From the Main Unit
Dimensions (W x D x H): 642 x 657 x 456 mm (attached to the main unit)
Weight: Approx. 27 kg

Finisher Model (iR-ADV DX 717iZ)

Tray Capacity (with 80g/m² paper, same paper type):
Upper Tray: A4, A5R, B5: 400 sheets
Lower Tray: A4, A5R, B5: 100 sheets
Main unit output tray: A4, A5, A5R, A6, B5: 500 sheets

Paper Type: Thin, Plain, Recycled, Heavy, Color, Bond, Transparency*, Envelope^*14

Staple Paper Weight: 60 to 120g/m²
Staple Position: Corner
Staple Paper Size: A4, Custom size (210.0 x 279.4 mm to 216.0 x 355.6 mm)
Staple Capacity: 30 sheets (60 to 90g/m²), 20 sheets (91 to 120g/m²)

Card Readers

Copy Card Reader-F1
Copy Card Reader Attachment-B5

Device Security

iR-ADV Security Kit-AR1 for IEEE 2600 Common Criteria Certification (available at a later date)

Print Accessories

PCL International Font Set-A1
PCL Asian Font Set-A1

Barcode Printing

Barcode Printing Kit-D1

System Accessories

Copy Control Interface Kit-A1
Connection Kit-A2 for Bluetooth LE
NFC Kit-E1

Fax Accessories

Super G3 FAX Board-AT1
Remote Fax Kit-A1
IP FAX Expansion Kit-B1

Accessibility Accessories

ADF Access Handle-A1

Consumables

Staple-P1
